Guangzhou Maichi Packaging Equipment Co., Ltd. was established in 2014, focusing on advanced vacuum packaging technology, widely applied in various industries such as food, pharmaceuticals, and electronics. Its external vacuum packaging machine effectively extends the shelf life of food through gas flushing and nitrogen gas infusion technology.

Packaging Materials:

Widely suitable for various foods such as meat, seafood, vegetables, fruits, and nuts.

Main Parameters:

Equipment Name: 1000 External Vacuum Packaging Machine

Power Voltage: Three-phase / 380V

Sealing Length: 1000mm × 1 strip

Sealing Height: 950-1400mm

Sealing Rotation Angle: 0-90 degrees (from vertical to horizontal)

Packaging Material: Suitable for various composite films or aluminum foil bags

Machine Material: Made of high-quality 304 stainless steel, ensuring durability and safety

Heat Sealing Instant Heating Power: 1400W × 1 strip

Worktable Height: Can be customized as required

Vacuum Efficiency: Up to 20 cubic meters per hour, ensuring efficient vacuuming

Minimum Absolute Vacuum: ≤200pa, ensuring effective vacuum packaging

Machine Size: 1071×1227×1850mm, suitable for most working environments

Total Power: 2KW, energy-efficient

Machine Weight: 200KG, stable and durable

PLC: Uses JT-16, with high control accuracy

Touch Screen: MCGS-TPC7012, user-friendly and intuitive operation interface

The 1000 External Vacuum Packaging Machine improves production efficiency through a series of automated operations. Operators only need to place the packaging material neatly, align the sealing area with the sealing bar, and then press the start button or step on the footswitch. The machine will automatically complete multiple actions, including bag pressing, vacuuming, gas flushing, secondary vacuuming, sealing, cooling, and return to the original position. The equipment offers various operation modes, greatly enhancing ease of operation and work efficiency.
